2-Port USB 2.0 Peripheral Switch

Product Code : US221A

Brand Category : Docks and Switches

Description

Enables two computers to share a single USB peripheral device
Simple port selection via pushbuttons, configuration utility, or Auto Switch function
Auto Switch Function - no need for print server
USB 2.0 compliant
Supports transfer rates up to 480 Mbps
Multiplatform support - Windows and Mac
LED indicators display port focus
Overcurrent protection
Bus-powered
Hot pluggable
Buzzer indicates switching between computers
Supports multifunction printers

*The Auto Switch Function may be disabled if your operating system is Windows 8.1 or lower with a USB 3.0 driver installed

Technical Specification

Console Connections	2
Port Selection	Pushbuttons, Software, Auto Switch
Connectors
Computer	2 x USB Type B
Device	1 x USB Type A
LEDs
Devices	1 (Orange)
Selected	2 (Green)
Switches	1 x Pushbutton
Power	USB Bus Powered
Environmental
Operating Temperature	0–40˚C
Storage Temperature	-20–60˚C
Humidity	0–80% RH, Non-condensing
Physical Properties
Housing	Plastic
Weight	0.06 kg ( 0.13 lb )
Dimensions (L x W x H)	7.18 x 6.58 x 2.44 cm (2.83 x 2.59 x 0.96 in.)
