2-Port USB DisplayPort Secure KVM Switch (PSS PP v3.0 Compliant)

2-Port USB DisplayPort Secure KVM Switch (PSS PP v3.0 Compliant)

Product Code : CS1182DP

Brand Category : Secure KVM Switches


Description


"

  • NIAP Common Criteria Compliant
    • Compliant with PSS PP v3.0 (Protection Profile for Peripheral Sharing Switch, Version 3.0) security requirements




  • Multi-Layered Security
    • Restricted USB Connectivity – non-authorized HIDs (Human Interface Devices) or non-predefined CAC devices will be rejected / ignored
    • Always-on Chassis Intrusion Detection – renders the ATEN PSS PP v3.0 Secure KVM Switches inoperable when physical tampering is detected
    • Tamper-Evident Seals– provides visual indication of any attempt to access the ATEN PSS PP v3.0 Secure KVM Switches’ internal components
    • Non-Reprogrammable Firmware – prevents reprogramming the ATEN PSS PP v3.0 Secure KVM Switches
    • Port selection via pushbuttons only to enhance security
    • LED indicators for peripheral filtering and KVM security status
    • Rugged metal enclosure




  • Data Channel Isolation and Unidirectional Data Flow
    • Data Channel Isolation – prevents data leakage between connected computers via isolated channel per port
    • Unidirectional Data Flow – ensures unidirectional data flow between the console devices and the selected computer
    • ATEN PSS PP v3.0 Secure KVM Switches control and isolate data flow between the console devices and connected computers
    • Supports analog audio (speaker only)*




  • User Data Protection
    • User Data Protection – Keyboard/Mouse data buffer is automatically purged when switching KVM port focus




  • Security Management
    • KVM Log Data – provides administrative functions for authorized administrator to audit KVM log data
    • Configurable Device Filtering – USB CAC Port can be configured to allow/reject whitelisted / blacklisted devices via Admin logon function or Windows-based application
    • Supports enable / disable CAC function by port




  • Superior Video Quality
    • Superior video quality – up to 4K (3840 x 2160 @ 30 Hz)**
    • Video DynaSync™ – Exclusive ATEN technology eliminates boot-up display problems and optimizes resolutions when switching between ports

      * Only analog speaker data input is supported. The ATEN PSS PP v3.0 Secure KVM Switches does not convert digital audio to analog audio.
      ** DisplayPort Secure KVM Switch series supports console video output resolutions up to 4K @ 30 Hz.

"


Add to Query Cart PDF Download


Technical Specification


Computer Connections 2
Port Selection Pushbutton
Connectors
Console Ports 2 x USB Type-A Female (Black)
1 x 6-pin Mini-DIN Female (Purple)
1 x 6-pin Mini-DIN Female (Green)
1 x HDMI Female (Black)
1 x Mini Stereo Jack Female (Green; front panel)
KVM Ports 4 x USB Type-B Female (White)
2 x DisplayPort Female (Black)
2 x Mini Stereo Jack Female (Green)
Power 1 x 3-prong AC Socket
USB CAC Port 1 x USB Type-A Female (White; front panel)
Switches
Port Selection 2 x Pushbuttons
Reset 1 x Semi-recessed Pushbutton
Power 1 x Rocker
LEDs
Power 1 (Blue)
Online / Selected (KVM Port) 2 (Orange)
Online / Selected (CAC Port) 2 (Green)
Video 1 (Green)
Key Lock 3 (Green)
Emulation
Keyboard / Mouse USB
Video Max. 3840 x 2160 @ 30 Hz (UHD)
Maximum Input Power Rating 100–240V~; 50-60 Hz; 1A
Power Consumption AC110V:3.8W:37BTU
AC220V:3.8W:37BTU
Environmental
Operating Temperature 0-50°C
Storage Temperature -20-60°C
Humidity 0 - 80% RH, Non-condensing
Physical Properties
Housing Metal
Weight 1.76 kg ( 3.88 lb )
Dimensions (L x W x H) 33.50 x 16.43 x 4.40 cm
(13.19 x 6.47 x 1.73 in.)
