2 x 4 USB 3.2 Gen1 Peripheral Sharing Switch

2 x 4 USB 3.2 Gen1 Peripheral Sharing Switch

Product Code : US3324

Brand Category : Docks and Switches

Description

"
  • Enables 2 computers to share 4 USB 3.2 Gen1 devices
  • Simple port selection via remote port selector for convenient switch placement
  • USB 3.2 Gen1 compliant, supporting data transfer rates of up to 5Gbps
  • LEDs indicates which computer is active
  • Over-current protection
  • Micro USB power jack for additional power supply
  • Bus-powered – no external power supply needed
  • Plug and Play – no drivers or external power adapter needed
  • Multiplatform support – Windows, Linux and Mac
"

Add to Query Cart PDF Download

Technical Specification

Computer Connections2
Port SelectionRemote port selector
Connectors
Computer2 x USB Type B Femal (Blue)
Device4 x USB Type A Female (Blue)
Power (Optional)1 x USB micro B Female (Black)
Cable Length
USB CableUSB 3.2 Gen 1 B to A Cable 1.2m x 2
USB 3.2 Gen 1 B to C Cable 1.8m x 1
Remote Port Selector1.8 m
LEDs
Selected2 (White)
Environmental
Operating Temperature0–40°C
Storage Temperature-20–60°C
Humidity0–80% RH, Non-condensing
Physical Properties
HousingPlastic
Weight0.12 kg ( 0.26 lb )
Dimensions (L x W x H)9.37 x 9.30 x 2.68 cm
(3.69 x 3.66 x 1.06 in.)
