2 x 4 USB 3.2 Gen1 Peripheral Sharing Switches

2 x 4 USB 3.2 Gen1 Peripheral Sharing Switches

Product Code : US234

Brand Category : Docks and Switches

Description

  • Enables 2 computers to share 4 USB 3.2 Gen1 devices
  • Simple port selection via remote port selector for convenient switch placement
  • USB 3.2 Gen1 compliant, supporting data transfer rates of up to 5 Gbps
  • LEDs indicates which computer is active
  • Over-current protection
  • Multiplatform support – Windows, Linux and Mac
  • Bus-powered
  • Micro USB power jack for additional power supply
  • Hot pluggable, no driver or software required

Add to Query Cart PDF Download

Technical Specification

Computer Connections 2
Port Selection Remote port selector
Connectors
Computer 2 x USB Type B Femal (Blue)
Device 4 x USB Type A Female (Blue)
Power (Optional) 1 x USB micro B Female (Black)
Cable Length
USB Cable USB 3.2 Gen 1 B to A Cable 1.2m x 2
Remote Port Selector 1.8 m
LEDs
Selected 2 (White)
Environmental
Operating Temperature 0–40°C
Storage Temperature -20–60°C
Humidity 0–80% RH, Non-condensing
Physical Properties
Housing Plastic
Weight 0.12 kg ( 0.26 lb )
Dimensions (L x W x H) 9.37 x 9.30 x 2.68 cm
(3.69 x 3.66 x 1.06 in.)
