Secure in-band and out-of-band network access to serial consoles
In-band access of Ethernet
Browser access with an intuitive GUI
Terminal-based access with a menu-driven UI
Out-of-band access of dial-up modem
Modem dial-in/dial-back/dial-out
Front access USB ports for USB storage or for USB-based PC cards
Laptop USB Console (LUC) port for extra local console access via laptop computer
Dual Ethernet ports for failover or for dual IP addresses access
Dual power supply
Serial Console Management
Convenient and simple access via browser or Telnet/SSH client
Port access via Telnet/SSH client and third-party client such as PuTTY
Direct port access from Telnet client – bypassing login to SN
Convenient port access via the applet serial viewer from SN Web GUI
Selectable Telnet or SSH for the serial viewer
Selectable ActiveX or Java for the serial viewer
Comprehensive viewer function – Copy/paste, logging, data import, Macro, broadcast and Message Board
Sun Solaris ready – Sun ""break-safe""
Alert String
Command filter – Administrators can restrict users to execute only predefined commands*
Data buffering
Multiple users simultaneously access to the same port – up to 16 connections per port.
Selectable mode for multiple simultaneous access – Exclusive/Occupy/Share mode
Integrated with Power Over the NET product for port and power outlet association
Security
SSH and SSL (TLS v1.0 / TLS v1.1 / TLS v1.2) support
Secure login from browser with TLS 1.2 data encryption and RSA 2048-bit certificates
Configurable user permissions for port access and control
Configurable group permission for port access and control
Local and remote authentication and logging
SN0132 support RADIUS, TACACS+, LDAP/AD, and Kerberos
IP filtering and MAC filtering
High-Grade Security – supports FIPS 140-2 level 1 security standards that use an embedded FIPS 140-2 certified OpenSSL cryptographic module (Certificate #1747, #2398, #2473)
System Management
System configuration via Web browser of HTTP/HTTPS, Telnet/SSH client and local console
System log and event logging
Comprehensive logging and event notifi cation
ATEN Log server and Syslog server
SNMP agent
Event notification – SN0132 support notification of SMTP email, SNMP Trap, and SMS (with additional mobile device)
Backup/restore system configuration
Firmware upgradeable
Multi-browser support – Internet Explorer, Chrome, Firefox, Safari, Opera, Mozilla, and Netscape
Customizable global time zone
NTP for time server synchronization
DHCP for dynamic IP address assignment
IPv6 support
Integrated with CC2000 for data center centralized management
Serial Device Management
Versatile serial operating modes – SN0132 support Real COM, TCP Server, TCP Client, UDP, Serial Tunnel and Virtual Modem
128-bit/256-bit SSL encryption (TLS v1.0 / TLS v1.1 / TLS v1.2) for Real COM, TCP Server, TCP Client, Serial Tunnel and Virtual Modem
Multiple simultaneous connections to the same port – up to 16 connections per port
Real COM driver for Windows 2000/XP/Vista/7 and Windows Server 2003/2008
Real TTY driver for Linux
Fixed TTY driver for UNIX
Language
Web-based GUI multi-language – available for Japanese, Korean, German, Russian, Simplifi ed Chinese and Traditional Chinese
