4-Port PS/2 VGA KVM Switch

Product Code : CS84A

Brand Category : Desktop KVM Switches

Description

One PS/2 console controls 4 computers.
Computer selection via front panel pushbuttons and hotkeys.
Superior video quality- up to 1920 x 1440; DDC2B.
Supports Microsoft IntelliMouse, Logitech MouseMan, FirstMouse and IBM Scrollpoint Mouse.
Compact, Sturdy, Durable Metal Housing.
Keyboard and mouse emulation for error free booting.
Auto Scan function to monitor computer operation.
Bus-Powered.
OS Support:Windows 2000, Windows XP, Windows Vista, LINUX, Mac and FreeBSD

Technical Specification

Computer Connections	4
Port Selection	Hotkey, Pushbutton
Connectors
Console Ports	1 x HDB-15 Female (Blue) 1 x 6-pin Mini-DIN Female (Purple) 1 x 6-pin Mini-DIN Female (Green)
KVM Ports	4 x HDB-15 Male (Blue) 4 x 6-pin Mini-DIN Female (Purple) 4 x 6-pin Mini-DIN Female (Green)
Power	1 x DC Jack
Switches
Ports	4 x Pushbutton
LEDs
Online	4 (Orange)
Selected	4 (Green)
Emulation
Keyboard / Mouse	PS/2
Video	1920 x 1440 @ 60Hz; DDC2B
Scan Interval	5 seconds
Power Consumption	DC9V:0.3W:6BTU
Environmental
Operating Temperature	0°~50°C
Storage Temperature	-20°~60°C
Humidity	0~80% RH, Non-condensing
Physical Properties
Housing	Metal
Weight	0.78 kg ( 1.72 lb )
Dimensions (L x W x H)	21.00 x 8.80 x 5.55 cm (8.27 x 3.46 x 2.19 in.)
