4-Port USB 2.0 Cat 5 Extender over LAN

Product Code : UEH4102

Brand Category : Extenders

Description

Extends USB transmission over a Gigabit Ethernet Local Area Network (LAN)
ExtremeUSB® – supports transparent USB 2.0 signals and true plug-and-play (no software or drivers required)
Pre-paired networked configuration through MAC Address for simple installation. No pairing action required
Supports automatic connection link between Local and Remote units through DHCP
Up to 100m between extender and switch and between switches over CAT 5e/6/7 cables
Operates with all USB peripherals - flash drives, keyboards, mice, webcams, interactive whiteboards, and more
Works with all major operating systems: Windows®, OS X®, and Linux®

Technical Specification

Function	UEH4102L	UEH4102R
Connectors
USB Port	1 x USB Type B Female	4 x USB Type A Female
Link	1 x Gigabit Ethernet Female	1 x Gigabit Ethernet Female
Power	N/A	1 x DC Power Jack
USB Specification	USB 2.0 High/Full/Low Speed	USB 2.0 High/Full/Low Speed
USB Devices Supported	N/A	4 USB Devices
Power Consumption	BTU	DC5V:15WBTU
Network Protocol	10/100/1000BASE-T Ethernet (recommend 1000BASE-T Ethernet for best performance)	10/100/1000BASE-T Ethernet (recommend 1000BASE-T Ethernet for best performance)
Environmental
Storage Temperature	-20° - 70°C	-20° - 70°C
Humidity	0 - 80% RH, Non-condensing	0 - 80% RH, Non-condensing
Operating Temperature	0° - 50° C	0° - 50° C
Physical Properties
Weight	0.17 kg ( 0.39 lb )	0.19 kg ( 0.42 lb )
Housing	Metal	Metal
Dimensions (L x W x H)	10.00 x 7.60 x 2.60 cm (3.94 x 2.99 x 1.02 in.)	10.00 x 7.60 x 2.60 cm (3.94 x 2.99 x 1.02 in.)
