4-Port USB 2.0 Hub with Magnetic

4-Port USB 2.0 Hub with Magnetic

Product Code : UH284

Brand Category : Docks and Switches

Description

  • Provides 4 additional USB 2.0 ports to existing USB Systems.
  • Four independent, fully functional, 480 Mbps, downstream ports.
  • Fully compliant with the USB 2.0 specification.
  • Supports transfer rates of 1.5 / 12 /480 Mbps.
  • Per port overcurrent protection.
  • Compact design, easy to store at anywhere.
  • Built in Magnet Pad for quick mount and easy movement.
  • Plug-n-play.
  • Available in silver, black, and burgundy.
  • OS Support: Windows 2000, Windows XP, Mac and FreeBSD

Add to Query Cart PDF Download

Technical Specification

Connectors
USB Port1 x USB Mini Type B Female (Black)
Downstream4 x USB Type A Female (White)
Power1x DC Jack (Black)
LEDs
Power1 (Green)
Output Voltage (Per Port)+5V DC
Environmental
Operating Temperature0–40˚C
Storage Temperature-20–60˚C
Humidity0–80% RH, Non-condensing
Physical Properties
HousingPlastic
Weight0.04 kg ( 0.09 lb )
Dimensions (L x W x H)8.30 x 3.40 x 1.47 cm
(3.27 x 1.34 x 0.58 in.)
