4-Port USB DVI Dual Link Dual Display/Audio KVMP™ Switch

Product Code : CS1644A

Brand Category : Desktop KVM Switches

Description

One dual-screen USB console controls two/four dual-screen computers and two additional USB devices
Multi-View Display – Easily connect two CS1642A/1644A's units for a second dual-screen setup controlled through a single connection
Superior video quality – 2560 x 1600 at 60Hz (DVI Dual link); and 3D displays up to 1920 x 1200 at 120Hz (DVI Single link)
Supports widescreen resolutions
Independent switching of KVM, USB, and Audio focus
DVI digital and analog monitor support – fully compliant with DVI specifications; and HDCP compliant
Multiplatform support – Windows 2000/XP/Vista, Linux *, Mac, Sun,and FreeBSD
Sun/Mac keyboard support and emulation **
Video DynaSync, exclusive ATEN technology, to eliminate boot-up display problems and optimizes resolution when switching between ports

* Supports Linux Kernel 2.6 and higher. The CS1644A has a builtin USB 2.0 hub, so will not support PCs or OS that do not support USB 2.0.
** PC keyboard combinations emulate Mac keyboards.
** Mac keyboards only work with their own computers.

Technical Specification

Computer Connections	4
Port Selection	Hotkey, Pushbutton, Mouse
Connectors
Console Ports	2 x USB Type A Female (rear panel) 2 x DVI-I Female (White) 1 x 3.5mm Audio Jack Female (Green) 1 x 3.5mm Audio Jack Female (Pink)
KVM Ports	4 x USB Type B Female 8 x DVI-I Female (white) 4 x 3.5mm Audio Jack Female (Green) 4 x 3.5mm Audio Jack Female (Pink)
Daisy Chain Ports	1 x RJ-45 Female (rear panel)
Power	1 x DC Jack
USB Hub	2 x USB Type A Female (1 x front panel; 1 x rear panel)
LEDs
KVM	4 (Orange)
Audio	4 (Green)
USB Link	4 (Green)
Switches
Selected	5 x Pushbutton
Emulation
Keyboard / Mouse	USB
Video	DVI Dual Link: 2560 x 1600 @ 60Hz; 3D Display: 1920 x 1200 @ 120Hz
Scan Interval	1-99 secconds (default: 5 secs.)
Power Consumption	DC5.3V:5.34W:51BTU
Environmental
Operating Temperature	0–50°C
Storage Temperature	-20–60°C
Humidity	0-80% RH, Non-condensing
Physical Properties
Housing	Plastic, Metal
Weight	2.32 kg ( 5.11 lb )
Dimensions (L x W x H)	43.72 x 15.98 x 4.40 cm (17.21 x 6.29 x 1.73 in.)
