8 x 8 HDMI Matrix Switch with Scaler

8 x 8 HDMI Matrix Switch with Scaler

Product Code : VM5808HA

Brand Category : Video Matrix Switches


Description


  • Routes any of 8 HDMI sources to any of 8 HDMI displays
  • Local HDMI output – enables previewing of up to 8 video sources in a multi-view window
  • Multiple system configuration methods including front panel pushbuttons / RS-232 / Ethernet (Telnet / Web GUI) connection, ATEN Video Matrix Control app, and ATEN Control System
  • Device status can be viewed and controlled via ATEN Video Matrix Control App
  • Video Wall functionality via intuitive web GUI* allows for customization of up to 16 layouts for any type of video walls
  • Built-in scaler automatically converts input resolutions for optimal appearance on the display
  • FrameSync – prevents image tearing by synchronizing the scaler output frame rate to the input signal frame rate
  • ATEN Seamless Switch technology* – adopts FPGA to unify video formats so as to provide continuous video streams, real-time switching, and stable signal transmission
  • EDID Expert – selects optimum EDID settings for smooth power-up, high-quality display, and use of the best resolution across different screens
  • Audio enabled; HDMI audio can be extracted to stereo audio
  • HDMI (3D, Deep color); HDCP 1.4
  • Supports Dolby True HD and DTS HD Master audio
  • Supports Consumer Electronics Control (CEC)
  • ESD protection for HDMI
  • Firmware upgradeable
  • Rack mountable (1U design)

    *Note:
    1. If Seamless Switching is enabled, the video output will not display 3D, Deep Color or interlace (i.e., 1080i) resolutions. To make these features available, disabling Seamless Switching is a must.
    2. Videos may not display within range when Seamless Switch or Video Wall is enabled, in which case please adjust the display settings on your device.

Add to Query Cart PDF Download


Technical Specification


Video Input
Interfaces8 x HDMI Type A Female (Black)
Impedance100 Ω
Max. Distance5.0 m
Video Output
Interfaces8 x HDMI Type A Female (Black)
(Array Mode): 1 x HDMI Type A Female (Black)
Impedance100 Ω
Max. Distance15 m
Video
Max. Data Rate6.75 Gbps (2.25 Gbps Per Lane)
Max. Pixel Clock225 MHz
ComplianceHDMI (3D, Deep Color)
HDCP 1.4 Compatible
Consumer Electronics Control (CEC)
Max. ResolutionUp to 1080p
Max. DistanceUp to 15 m
Audio
Output1 x Mini Stereo Jack Female (Green)
Control
RS-232Connector: 1 x DB-9 Female (Black)
Baud rate and protocol:
Baud Rate: 19200, Data Bits: 8, Stop Bits:1, Parity: No, Flow Control: No
Ethernet1 x RJ-45 Female
EDID SettingsEDID Mode: Default / Port1 / Remix / Customized (EDID Wizard support)
Connectors
Power1 x 3-Prong AC Socket
Power
Maximum Input Power Rating100-240 VAC; 50-60 Hz; 1.0A
Power ConsumptionAC110V:58.1W:272BTU
AC220V:56.6W:265BTU
Environmental
Operating Temperature0-40°C
Storage Temperature-20 - 60°C
Humidity0 - 80% RH, Non-Condensing
Physical Properties
HousingMetal
Weight5.54 kg ( 12.2 lb )
Dimensions (L x W x H)43.24 x 37.82 x 4.40 cm
(17.02 x 14.89 x 1.73 in.)
Carton Lot1 pc
