Product Code : PE0210S
Brand Category : Rack PDU
| Function | PE0210SA | PE0210SB | PE0210SG |
| Electrical | |||
| Nominal Input Voltage | 100-120 VAC | 100-240 VAC | 100-240 VAC |
| Maximum Input Current | 20A Max (UL de-dated 16A Max) | 20A Max (UL derating 16A Max) | 16A (Max) |
| Input Frequency | 50-60 Hz | 50-60 Hz | 50-60 Hz |
| Input Connection | For A Plug: NEMA L5-20P For A2 Plug:NEMA 5-20P | NEMA L6-20P | For G Plug: IEC-320 C20 For Z Plug: Chinese 16A |
| Input Power | 2400VA(Max); 1920VA(UL de-rated) | 4800VA(Max); 3840VA(UL de-rated) | 3840VA(Max) |
| Outlet Type | (10) NEMA 5-20R | (10) IEC 320 C13 | (10) IEC 320 C13 |
| Maximum Output Current (Outlet) | 20A Max (UL de-dated 16A Max) | 15A Max (UL derating 12A Max) | 10A (Max) |
| Maximum Output Current (Bank) | 20A Max (UL de-dated 16A Max) | 20A Max (UL derating 16A Max) | 16A (Max) |
| Maximum Output Current (Total) | 20A Max (UL de-dated 16A Max) | 20A Max (UL derating 16A Max) | 16A (Max) |
| OPD(Overcurrent Protection Device) | Yes | Yes | Yes |
| Physical Properties | |||
| Dimensions (L x W x H) | 48.20 x 4.44 x 4.50 cm (18.98 x 1.75 x 1.77 in.) | 48.20 x 4.44 x 4.50 cm (18.98 x 1.75 x 1.77 in.) | 48.20 x 4.44 x 4.50 cm (18.98 x 1.75 x 1.77 in.) |
| Weight | 0.67 kg ( 1.48 lb ) | 0.67 kg ( 1.48 lb ) | 0.67 kg ( 1.48 lb ) |
| Power Cord Length | 10ft(12#) | 10ft(12#) | 10ft(3*2.5mm2) |
| Environmental | |||
| Temperature (Operating / Storage) | 0 – 40℃ / -20 – 60℃ *When the environmental temperature comes close 40 degrees, it is recommended to lower the load to 60% to comply to the safety regulations. | 0 – 40℃ / -20 – 60℃ *When the environmental temperature comes close 40 degrees, it is recommended to lower the load to 60% to comply to the safety regulations. | 0 – 40℃ / -20 – 60℃ *When the environmental temperature comes close 40 degrees, it is recommended to lower the load to 60% to comply to the safety regulations. |
| Elevation (Operating / Storage) | 3000m | 3000m | 3000m |
| Compliance | |||
| EMC Verification | FCC Class A | FCC Class A | - |
| Safety Verification | UL | UL | LVD |
