Basic Metered 0U PDU with Surge Protection

Basic Metered 0U PDU with Surge Protection

Product Code : PE1116S

Brand Category : Rack PDU


Description


  • Space saving 0U rack mount design
  • IEC or NEMA outlet models
  • Surge protection
  • Dual 3-digit 7-segment displays to show current and voltage
  • Real-time PDU current monitoring when used in conjunction with the EC1000 Energy Box

Add to Query Cart PDF Download


Technical Specification


Function PE1116SA PE1116SG
Electrical
Nominal Input Voltage 100-120 VAC 100-240 VAC
Maximum Input Current 15A Max
(UL de-rated 12A Max)
(PSE 10A)
10A Max
Input Frequency 50-60 Hz 50-60 Hz
Input Connection NEMA 5-15P IEC-320 C14
Input Power 1800VA(Max);
1440VA(UL de-rated)
2400VA(Max)
Outlet Type (16) NEMA 5-15R (16) IEC 320 C13
Maximum Output Current (Outlet) 15A Max
(UL derating 12A Max)
(PSE 10A)
10A Max
Maximum Output Current (Bank) 15A Max
(UL derating 12A Max)
(PSE 10A)
10A Max
Maximum Output Current (Total) 15A Max
(UL derating 12A Max)
(PSE 10A)
10A Max
OPD(Overcurrent Protection Device) Yes Yes
Physical Properties
Dimensions (L x W x H) 96.71 x 4.44 x 6.00 cm
(38.07 x 1.75 x 2.36 in.)
96.71 x 4.44 x 6.00 cm
(38.07 x 1.75 x 2.36 in.)
Weight 1.30 kg ( 2.86 lb ) 1.30 kg ( 2.86 lb )
Power Cord Length 10ft(14#) 10ft(3×1.0mm2)
Environmental
Temperature (Operating / Storage) 0 – 40℃ / -20 – 60℃ 0 – 40℃ / -20 – 60℃
Elevation (Operating / Storage) 3000m 3000m
Compliance
EMC Verification FCC Class A CE Class A
Safety Verification UL, other by request CE,LVD, UL
