Basic Metered 0U PDU with Surges Protection

Product Code : PE1224S

Brand Category : Rack PDU

Description

Space saving 0U rack mount design
IEC or NEMA outlet models
Surge protection
Dual 3-digit 7-segment displays to show current and voltage
Real-time PDU current monitoring when used in conjunction with the EC1000 Energy Box

Technical Specification

Function	PE1224SA	PE1224SB	PE1224SG
Electrical
Nominal Input Voltage	100-120 VAC	100-240 VAC	100-240 VAC
Maximum Input Current	20A Max (UL de-rated 16A Max)	20A Max (UL de-rated 16A Max)	16A Max
Input Frequency	50-60 Hz	50-60 Hz	50-60 Hz
Input Connection	For A Plug: NEMA L5-20P For A2 Plug: NEMA 5-20P	NEMA L6-20P	IEC-320 C20
Input Power	2400VA(Max); 1920VA(UL de-rated)	4800VA(Max); 3840VA(UL de-rated)	3840VA(Max)
Outlet Type	(24) NEMA 5-20R	(22) IEC 320 C13, (2) IEC 320 C19	(22) IEC 320 C13, (2) IEC 320 C19
Maximum Output Current (Outlet)	20 Max (UL de-rated 16A Max)	C19: 20A Max (UL de-rated 16A Max) C13: 15A Max (UL de-rated 12A Max)	C19: 16A Max C13: 10A Max
Maximum Output Current (Bank)	20 Max (UL de-rated 16A Max)	20 Max (UL de-rated 16A Max)	16A Max
Maximum Output Current (Total)	20 Max (UL de-rated 16A Max)	20 Max (UL de-rated 16A Max)	16A Max
OPD(Overcurrent Protection Device)	Yes	Yes	Yes
Physical Properties
Dimensions (L x W x H)	108.71 x 4.44 x 6.00 cm (42.8 x 1.75 x 2.36 in.)	108.71 x 4.44 x 6.00 cm (42.8 x 1.75 x 2.36 in.)	108.71 x 4.44 x 6.00 cm (42.8 x 1.75 x 2.36 in.)
Weight	1.60 kg ( 3.52 lb )	1.60 kg ( 3.52 lb )	1.60 kg ( 3.52 lb )
Power Cord Length	10ft(12#)	10ft(12#)	10ft(3×1.5mm2)
Environmental
Temperature (Operating / Storage)	0 – 40℃ / -20 – 60℃	0 – 40℃ / -20 – 60℃	0 – 40℃ / -20 – 60℃
Elevation (Operating / Storage)	3000m	3000m	3000m
Compliance
EMC Verification	FCC Class A	FCC Class A	CE Class A
Safety Verification	UL, other by request	UL, other by request	CE,LVD, UL
