Product Code : UC3020
Brand Category : Capture
"
"
| Connectors | |
| Video In | 1 x HDMI Type A Female (Black) |
| USB Port | USB 3.2 Gen1 Type-C Male (White) (USB-C to USB-A adapter package included, Black ) |
| Video Resolution | Video input: 1080p60, 720p60, 480p60, HDMI 1.4b support (unencrypted) |
| Audio Sampling | 16-bit PCM audio, 44.1KHz and 48KHz |
| Output | Uncompressed 1080p, 720p60 and 480p60 UVC video stream with UAC audio (Uncompressed video stream is only available on USB3.2 connection) |
| Environmental | |
| Operating Temperature | 0 - 40 ºC |
| Storage Temperature | -20 – 60 ºC |
| Humidity | 0 - 80% RH, Non-Condensing |
| Minimum Hardware Requirements | PC/Mac: CPU: Intel® i3 Dual Core 2.8Ghz or higher RAM: 4GB or more One USB-C interface or USB-A interface Smartphone: Android device with UVC support and USB-C interface* *Latest UC3020 FW upgrade for smartphone support is required. For detail UVC compatible device list, please refer to following info revealed by third party App. https://www.camerafi.com/supported-devices/ |
| OS Support | Windows 10 and above * Mac OS X 10.13 and above Android 5.0.1 and above with UVC support *Window 7 requires driver installation |
| Physical Properties | |
| Housing | Aluminum |
| Weight | 0.04 kg ( 0.09 lb ) |
| Dimensions (L x W x H) | 4.20 x 7.30 x 1.40 cm (1.65 x 2.87 x 0.55 in.) |
