Product Code : UC3021
Brand Category : Capture
| Connectors | |
| Video In | 1 x HDMI Type A Female (Black) |
| Video Output | 1 x HDMI Type A Female (Video Loop-out , Black) |
| USB Port | USB 3.2 Gen1 Type-C Female (Black) (USB-C to USB-C and USB-C to USB-A Cable package included) |
| Power (Optional) | 1 x USB-C Female Support Power Delivery 3.0 for laptop charging up to 60W, power profiles include 5V, 9V, 12V, 15V, 20V (additional USB-C power adapter needed)* *For device charging, a Limited Power Source (LPS) certified single port USB-C PD Power Adapter is recommended. |
| Video Resolution | Video input: 2160p60, 1080p60, 720p60 and 480p60, HDMI 2.0 support (unencrypted) Video Loop-out: 2160p60, 1080p60, 720p60 and 480p60, HDMI 2.0 support (unencrypted) |
| Audio Sampling | 16-bit PCM audio, 44.1KHz and 48KHz |
| Output | Uncompressed 1080p60, 720Pp60 & 480p60 UVC video stream with UAC audio (Uncompressed video stream is only available on USB3.1 connection) |
| Power Consumption | 5V:3WBTU |
| Minimum Hardware Requirements | PC/Mac: CPU: Intel® i3 Dual Core 2.8Ghz or higher RAM: 4GB or more One USB-C interface or USB-A interface Smartphone: Android device with UVC support and USB-C interface* *For detail UVC compatible device list, please refer to following info revealed by third party App. https://www.camerafi.com/supported-devices/ |
| OS Support | Windows 10 and above Mac OS X 10.13 and above Android 5.0.1 and above with UVC support |
| Environmental | |
| Operating Temperature | 0 - 40 ºC |
| Storage Temperature | -20 – 60 ºC |
| Humidity | 0 - 80% RH, Non-Condensing |
| Physical Properties | |
| Housing | Plastic |
| Weight | 0.09 kg ( 0.2 lb ) |
| Dimensions (L x W x H) | 11.49 x 8.49 x 2.00 cm (4.52 x 3.34 x 0.79 in.) |
