DVI EDID Emulator with Programmer

Product Code : VC060

Brand Category : Video Converters

Description

Superior video quality – HDTV resolutions of 480i, 480p, 720i, 720p, 1080i, 1080p (1920 x 1080); VGA, SVGA, XGA, SXGA, UXGA and WUXGA (1920 x 1200)
EDID Wizard – allows a user an easy way to manage EDID settings
EDID mode selection – Default, Learning , Programming
Automatically manages EDID communication between connected devices
Signaling rates up to 2.25 Gbits in support of 1080p display
LED indication of video source devices
Supports wide screen
Supports hot-plugging
Non-Powered *
* If the video source is not receiving enough power an external power cord should be connected.

Technical Specification

Max. Video Resolution	WUXGA (1920 x 1200)
Data Rate	2.25 Gbits
Connectors
Power	1 x DC Jack
Power Consumption	DC5V:0.13W:1BTU
Environmental
Operating Temperature	0 - 50 ºC
Storage Temperature	-20 - 60 ºC
Humidity	0 - 80% RH, Non-Condensing
Physical Properties
Housing	Metal
Weight	0.15 kg ( 0.33 lb )
Dimensions (L x W x H)	7.90 x 7.86 x 2.45 cm (3.11 x 3.09 x 0.96 in.)
Carton Lot	5 pcs
Video Input
Interfaces	1 x DVI-I Female (White)
Impedance	100 Ω
Video Output
Interfaces	1 x DVI-I Female (White)
Impedance	100 Ω
EDID Settings	EDID Mode: Default / Learn / Customized (EDID Wizard support)
