Product Code : VE600A
Brand Category : Video Extenders
| Function | VE600AL | VE600AR |
| Video Input | ||
| Interfaces | 1 x DVI-D Female (White) | N/A |
| Impedance | 100 Ω | N/A |
| Max. Distance | 1.8 m | N/A |
| Video Output | ||
| Interfaces | N/A | 1 x DVI-D Female (White) |
| Impedance | N/A | 100 Ω |
| Video | ||
| Max. Data Rate | 6.75 Gbps (2.25 Gbps Per Lane) | 6.75 Gbps (2.25 Gbps Per Lane) |
| Max. Pixel Clock | 225 MHz | 225 MHz |
| Compliance | HDCP Compatible | HDCP Compatible |
| Max. Resolutions / Distance | Up to 1080p@40m; 1080i@60m | Up to 1080p@40m; 1080i@60m |
| Audio | ||
| Input | 1 x Mini Stereo Jack Female (Green) | N/A |
| Output | N/A | 1 x Mini Stereo Jack Female (Green) |
| Connectors | ||
| Power | 1 x DC Jack | 1 x DC Jack |
| Power Consumption | DC5.3V:1.56W:7BTU | DC5.3V:0.76W:4BTU |
| Environmental | ||
| Operating Temperature | 0 - 50°C | 0 - 50°C |
| Storage Temperature | -20 - 60°C | -20 - 60°C |
| Humidity | 0 - 80% RH, Non-Condensing | 0 - 80% RH, Non-Condensing |
| Physical Properties | ||
| Housing | Metal | Metal |
| Weight | 0.17 kg ( 0.37 lb ) | 0.17 kg ( 0.37 lb ) |
| Dimensions (L x W x H) | 9.13 x 5.60 x 2.40 cm (3.59 x 2.2 x 0.94 in.) | 9.13 x 5.60 x 2.40 cm (3.59 x 2.2 x 0.94 in.) |
| Carton Lot | 20 pcs | 20 pcs |
