IA-20SIP

IP/SIP audio interface to analog audio. It allows to transmit audio from any SIP device to an analog public address system: amplifier, preamplifier, power unit... The unit is bidirectional, it also allows to connect an analog audio source (microphone, musical source ...) and transmit the signal to SIP devices.

• Parameter configuration via WEB server. • Local power supply 5 Vdc (I905SIP) oPoE. • Direct audio output for loudspeaker (8 Ohm, 2 W). • AUX audio outputs (0 dB) and MIC (-60 dB). • Relay contact output (activation by DMTF). • Open collector priority output (activated in connection). • Indicators: power supply, call and audio level. • Audio input with selectable level, AUX/MIC. • Input contact for call (intercommunication) or priority (PA). • Operating mode: broadcaster, receiver or bidirectional.
