Microphone desk with 4 zones selection for PM-804

Product Code : PM-4Z

Brand Category : Matrix Mixer 8 x 4

Description

Matrix mixer with 8 audio inputs and 4 outputs. First four inputs have selectable sensitivity (microphone / line) and three band EQ, and the other four are with line sensitivity. The eight inputs are assignable to any output. The mixer can be controlled remotely from a microphone desk (PM-4Z) or wall controls (WP-1) .

Input sensitivity	- 60 dB ± 3 dB / 600 Ω balanced
Frequency response (-1 dB)	45 Hz ~ 15 kHz / ± 1 dB
Signal to Noise ratio	90 dB
Rated output level	0 dB / 600 Ω unbalanced
T.H.D.	< 0>
Operating temperature	0º ~ 40º C with 95 % humidity
Net weight	0.9 kg
Dimensions (width x height x depth)	140 x 60 x 205 mm

Technical Specification

Input sensitivity	- 60 dB ± 3 dB / 600 Ω balanced
Frequency response (-1 dB)	45 Hz ~ 15 kHz / ± 1 dB
Signal to Noise ratio	90 dB
Rated output level	0 dB / 600 Ω unbalanced
T.H.D.	< 0>
Operating temperature	0º ~ 40º C with 95 % humidity
Net weight	0.9 kg
Dimensions (width x height x depth)	140 x 60 x 205 mm
