PMs-4Z

PMs-4Z

Product Code : PMs-4Z

Brand Category : Matrix Mixer 8 x 4


Description


Matrix mixer with 8 audio inputs and 4 outputs. First four inputs have selectable sensitivity (microphone / line) and three band EQ, and the other four are with line sensitivity. The eight inputs are assignable to any output. The mixer can be controlled remotely from a microphone desk (PM-4Z) or wall controls (WP-1) .


Add to Query Cart


Technical Specification


Input sensitivity

- 60 dB ± 3 dB / 600 Ω balanced

Frequency response (-1 dB)

45 Hz ~ 15 kHz / ± 1 dB

Signal to Noise ratio

  • 90 dB

Rated output level

0 dB / 600 Ω unbalanced

T.H.D.

< 0,1 % (a 1 kHz)

Operating temperature

0º ~ 40º C with 95 % humidity

Net weight

0.9 kg

Dimensions (width x height x depth)

140 x 60 x 205 mm
