TH-02F

Product Code : L411

Brand Category : Intercoms for hospitals and seniors residences

Description

Multifunction substation with call, presence and intercom with master or other substations

A multifunction intercommunicator with the possibility of establishing all kinds of call and presence with the central, communicating with it and with other intercommunicators. Suitable for rooms in hospitals, clinics and residences. Once the medical staff has signaled presence, it can receive calls, make a connection and talk with the intercommunicator that has produced the most priority call.

Technical Specification

Power supply	24 Vdc
Central connection	5-line SMC bus
Local connection buttons	2 x 0.5 mm2, max. 20 m
Local connection lamps	3 x 0.5 mm2, max. 20 m
Loudspeaker	8 Ohm, 4 W maximum
Dimensions (mm)	230 x 140 x 10
Finish	ABS, ivory colour
Box for flush installation	2010M model
Surface box	CAJ-TH model
