True 4K HDMI / USB HDBaseT 3.0 Transceiver

• Extends uncompressed True 4K HDMI signals up to 100 m over a single Cat 6a cable (HDBaseT 3.0 Certified Cat 6a U/ FTP cable* / ATEN 2L-2920 Cat 6a cable) with zero latency
• Flexible for deployment – can be configured as a transmitter or receiver depending on the AV solution
• Compliant with HDBaseT 3.0 standards – transmits high-quality video, full range IR, bi-directional RS-232, Gigabit Ethernet, independent stereo audio and USB 2.0 signals channel bypass
• HDMI (3D, Deep Color, 4K/60Hz); HDCP 2.3 compliant
• Superior video quality – up to 4096 x 2160 @ 60 Hz (4:4:4); HDR, HDR+, Dolby Vision supported
• Supports HDMI audio embedding / de-embedding functions
• Supports HDMI local output
• Compliant with the USB 2.0 standard for a wide range of USB peripherals compatibility
• LED indication of HDBaseT and HDMI signal status for easier recognition
• Fanless fin heat sink enclosure – elevates durability and reliability by preventing overheating, fan malfunctions, and noises
• Supports extremely high refresh rates up to 240 Hz for the connected display
• Firmware upgradable
• Built-in 8KV / 15KV ESD protection
• Plug-and-play
• Rack-mountable

* Cat 6a U/FTP is the recommended setting. The skewless nature and inter-pair shielding of FTP provides the better near-end crosstalk (NEXT, source end) and far-end crosstalk (FEXT, receiver end) parameters required to achieve the maximum performance and distance.
