U-ML

Product Code : L368FU

Brand Category : Call and signaling modules

Description

Handheld calling unit with call and light control buttons, for U-PT

Signalling and call mechanism for flush mounting and signalling of call to the centres. It is connected to a remote unit (UR or UC series) or to a TH-02F/TH-03F intercommunicator to complete the equipment of the call points. The mechanism has buttons for presence and normal call, emergency call, USB connector for U-ML control, disconnected control warning and LEDs of call in progress and active presence. For universal box, it does not include a frame (M-420W).

Technical Specification

Power supply	24 V DC
Consumption	24 mA
Dimensions (mm)	45 x 45 x 45
Finish	ABS with ivory cover
Connections (push buttons)	2 x 0,25 mm2 (to TH / UR)
Connections (LEDs)	3 x 0,25 mm2 (to TH / UR)
