Product Code : UH3235
Brand Category : Docks and Switches
| Computer Connections | 1 |
| Cable Length | 50 cm |
| Connectors | |
| Computer | 1 x USB-C Female (Black) |
| Device | 1 x USB 2.0 Type A Female (Black)* 1 x USB 3.2 Gen 1 Type A Female (Blue)** *Supports max. 5V, 0.3A output **Supports max. 5V, 0.7A output |
| Video Output | 1 x HDMI Female (Black) |
| Power | 1 x USB-C DC-in Female* *Support Power Delivery 2.0 for charging up to 60W, power profiles include 5V, 9V, 15V, 20V (additional USB-C PD power adapter needed) *For mobile device charging, a Limited Power Source (LPS) certified single port USB-C PD Power Adapter over 25 Watt is recommended. |
| Video Resolution | 3840 x 2160@30hz |
| Power Consumption | DC5V:7.5W:33BTU |
| System Requirements | • Windows 10 and above, USB-C enabled computer with DP Alt Mode* * With Intel 7th-Generation Core Processor (Kaby-Lake) and above. More info about CPU generation, please find: https://www.intel.com/content/www/us/en/processors/processor-numbers.html • Mac OS X 10.12 and above, USB-C enabled computer • Android 8.0 and later, USB-C enabled Smartphone with DP Alt Mode** **Only Samsung and Huawei support PC-like operation, others only support mirror mode. For a list of supporting mobile device, refer to UH3235’s user manual. • iPadOS 13.1 and above, iPad Pro (USB-C) |
| Environmental | |
| Operating Temperature | 0–40°C |
| Storage Temperature | -20–60°C |
| Humidity | 0–80% RH, Non-condensing |
| Physical Properties | |
| Housing | Plastic |
| Weight | 0.05 kg ( 0.11 lb ) |
| Dimensions (L x W x H) | 9.30 x 7.00 x 1.50 cm (3.66 x 2.76 x 0.59 in.) |
