USB-C to VGA Adapters

Product Code : UC3002A

Brand Category : Converters

Description

Transfer high-quality videos from a USB-C enabled laptop or smarphone to a 1920 x 1200@60Hz VGA display, or projector*
Premium casing can resists signal interference during video transmission and heat insulation
Compact and lightweight design
Works with all major operating systems: Windows®, OS X®, iPad Pro 3rd gen and Android
Plug-and-Play – no software required
Compatible with Thunderbolt 3 (USB-C)

*With Intel 7th- Generation Core Processor (Kaby Lake) and above. For video output to work through a USB-C port, it must support DP Alt Mode.

Technical Specification

Video Input
Interfaces	1 x USB-C Male (Black)
Video Output
Interfaces	1 x HDB-15 Female (Black)
Video
Max. Pixel Clock	148.5 MHZ
Max. Resolution	1920 x 1200@60Hz
Compliance	USB3.1 Type-C with DP Alt Mode (Thunderbolt™ 3 Compatible) USB Billboard Device Class
System Requirements	Windows 10 and above, USB-C enabled computer with DP Alt Mode* * With Intel 7th-Generation Core Processor (Kaby-Lake) and above. More info about CPU generation, please ﬁnd: https://www.intel.com/content/www/us/en/processors/processor-numbers.html Mac OS X 10.12 and above, USB-C enabled computer Android 8.0 and later, USB-C enabled Smartphone with DP Alt Mode iOS 12.1 and above, iPad Pro 3rd generation (2018)
Environmental
Operating Temperature	0 - 40 ºC
Storage Temperature	-20 - 60 ºC
Humidity	0 - 80% RH, Non-Condensing
Physical Properties
Housing	Aluminum
Weight	0.02 kg ( 0.06 lb )
Dimensions (L x W x H)	3.95 x 1.40 x 9.60 cm (1.56 x 0.55 x 3.78 in.)
